ImageSwitcher

Description

To apply some animation to the image when it transitions from one image to another, you need to use the ImageSwitcher together with the Gallery view.

Example

Modify the activity_main.xml file by adding the following statements:


<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:orientation="vertical" >

    <TextView
        android:layout_width="fill_parent"
        android:layout_height="wrap_content"
        android:text="Images of Android" />

    <Gallery
        android:id="@+id/gallery1"
        android:layout_width="fill_parent"
        android:layout_height="wrap_content" />

    <ImageSwitcher
        android:id="@+id/switcher1"
        android:layout_width="fill_parent"
        android:layout_height="fill_parent"
        android:layout_alignParentLeft="true"
        android:layout_alignParentRight="true"
        android:layout_alignParentBottom="true" />

</LinearLayout>

Save the following to res/values/attrs.xml.


<?xml version="1.0" encoding="utf-8"?>
<resources>
   <declare-styleable name="Gallery1">
       <attr name="android:galleryItemBackground" />
   </declare-styleable>
</resources>


Add the following statements to the MainActivity.java file:


package com.java2s.myapplication3.app;
/*w  w  w .j  a  va  2s  .c  om*/
import android.app.Activity;
import android.content.Context;
import android.content.res.TypedArray;
import android.os.Bundle;
import android.view.View;
import android.view.ViewGroup;
import android.view.ViewGroup.LayoutParams;
import android.view.animation.AnimationUtils;
import android.widget.AdapterView;
import android.widget.AdapterView.OnItemClickListener;
import android.widget.BaseAdapter;
import android.widget.Gallery;
import android.widget.ImageSwitcher;
import android.widget.ImageView;
import android.widget.ViewSwitcher.ViewFactory;

public class MainActivity extends Activity implements ViewFactory {
    Integer[] imageIDs = {
            R.drawable.ic_launcher,
            R.drawable.ic_launcher,
            R.drawable.ic_launcher,
            R.drawable.ic_launcher,
            R.drawable.ic_launcher,
            R.drawable.ic_launcher,
            R.drawable.ic_launcher
    };

    private ImageSwitcher imageSwitcher;

    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        imageSwitcher = (ImageSwitcher) findViewById(R.id.switcher1);
        imageSwitcher.setFactory(this);
        imageSwitcher.setInAnimation(AnimationUtils.loadAnimation(this,
                android.R.anim.fade_in));
        imageSwitcher.setOutAnimation(AnimationUtils.loadAnimation(this,
                android.R.anim.fade_out));

        Gallery gallery = (Gallery) findViewById(R.id.gallery1);
        gallery.setAdapter(new ImageAdapter(this));
        gallery.setOnItemClickListener(new OnItemClickListener()
        {
            public void onItemClick(AdapterView<?> parent,
                                    View v, int position, long id)
            {
                imageSwitcher.setImageResource(imageIDs[position]);
            }
        });
    }

    public View makeView()
    {
        ImageView imageView = new ImageView(this);
        imageView.setBackgroundColor(0xFF000000);
        imageView.setScaleType(ImageView.ScaleType.FIT_CENTER);
        imageView.setLayoutParams(new
                ImageSwitcher.LayoutParams(
                LayoutParams.FILL_PARENT,
                LayoutParams.FILL_PARENT));
        return imageView;
    }

    public class ImageAdapter extends BaseAdapter
    {
        private Context context;
        private int itemBackground;

        public ImageAdapter(Context c)
        {
            context = c;
            //setting the style
        //    TypedArray a = obtainStyledAttributes(R.styleable.Gallery1);
        //    itemBackground = a.getResourceId(
         //           R.styleable.Gallery1_android_galleryItemBackground, 0);
       //     a.recycle();
        }

        //returns the number of images
        public int getCount()
        {
            return imageIDs.length;
        }

        //returns the item
        public Object getItem(int position)
        {
            return position;
        }

        //returns the ID of an item
        public long getItemId(int position)
        {
            return position;
        }

        //returns an ImageView view
        public View getView(int position, View convertView, ViewGroup parent)
        {
            ImageView imageView = new ImageView(context);

            imageView.setImageResource(imageIDs[position]);
            imageView.setScaleType(ImageView.ScaleType.FIT_XY);
            imageView.setLayoutParams(new Gallery.LayoutParams(150, 120));
            imageView.setBackgroundResource(itemBackground);

            return imageView;
        }
    }

}
