The TableLayout groups views into rows and columns.

You use the <TableRow> element to designate a row in the table. Each row can contain one or more views.

Each view you place within a row forms a cell. The width of each column is determined by the largest width of each cell in that column.

Example

<TableLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_height="fill_parent"
    android:layout_width="fill_parent" >
    <TableRow>
        <TextView
            android:text="User Name:"
            android:width ="120dp"
            />
        <EditText
            android:id="@+id/txtUserName"
            android:width="200dp" />
    </TableRow>
    <TableRow>
        <TextView
            android:text="Password:"
            />
        <EditText
            android:id="@+id/txtPassword"
            android:password="true"
            />
    </TableRow>
    <TableRow>
        <TextView />
        <CheckBox android:id="@+id/chkRememberPassword"
            android:layout_width="fill_parent"
            android:layout_height="wrap_content"
            android:text="Remember Password"
            />
    </TableRow>
    <TableRow>
        <Button
            android:id="@+id/buttonSignIn"
            android:text="Log In" />
    </TableRow>
</TableLayout>

Note

In the preceding example, there are two columns and four rows in the TableLayout. The cell directly under the Password TextView is populated with a <TextView/> empty element.
