Android How to - React to configuration changed event








The following code shows how to React to configuration changed event.

Example

Set the config change masks.

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.java2s.myapplication3.app" >
    <uses-sdk
        android:minSdkVersion="8"
        android:targetSdkVersion="18" />

    <application
        android:allowBackup="true"
        android:icon="@drawable/ic_launcher"
        android:label="java2s.com"
        android:theme="@style/AppTheme" >
        <activity
            android:name="com.java2s.myapplication3.app.MainActivity"
            android:label="java2s.com"
            android:configChanges="orientation|keyboardHidden|screenSize"
            >
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
    </application>

</manifest>

Layout activity_main.xml file

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
  android:orientation="vertical"
  android:layout_width="fill_parent"
  android:layout_height="fill_parent">
  <ToggleButton
    android:id="@+id/toggleButton"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:textOff="Lock"
    android:textOn="LOCKED"
  />
</LinearLayout>

Main activity Java code

/*  w  w w  .j a va  2 s.  c o  m*/
package com.java2s.myapplication3.app;

import android.app.Activity;
import android.content.res.Configuration;
import android.os.Bundle;

public class MainActivity extends Activity {

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        loadView();
    }
    @Override
    public void onConfigurationChanged(Configuration newConfig) {
        super.onConfigurationChanged(newConfig);
        saveState();
        loadView();
    }
    private void saveState() {
        //Implement any code to persist the UI state
    }
    private void loadView() {
        setContentView(R.layout.activity_main);
    }
}
